2024 - 06 - 12Front view of the system of Dell PowerEdge R960
Dell PowerEdge R960 is one of the most popular one among all servers,here we introduce you the front view of the system of Dell PowerEdge R960. Harnessing the power of up to 4x 5th Gen Intel Xeon Scalable processors, each with up to 64 cores each and optional Intel QuickAssist Technology, the Dell PowerEdge R960 server features many scale-up capabilities. Figure 1. Front view of 32 x 2.5-inch drive system Figure 2. Front view of 24 x 2.5-inch drive system Figure 3. Front view of 16 x 2.5-inch drive system Figure 4. Front view of 8 x 2.5-inch drive system Figure 5. Front view of 16 x EDSFF E3.S drive system Figure 6. Front view of 8 x 2.5-inch with 16 x EDSFF E3.S drive system Table 1. Features available on the front of the system ITEM PORTS, PANELS, AND SLOTS ICON DESCRIPTION 1 Left control panel N/A Contains the system health, system ID, and the status LED indicator. 2 Drive N/A Enables you to install drives that are supported on your system. 3 Right control panel N/A Contains the power button, VGA port, USB port, iDRAC Direct (Micro-AB USB) port, and the iDRAC Direct status LED. 4 Express Service Tag N/A The Express Service Tag...
