2024 - 08 - 06Front view of the system of Dell PowerEdge R860
Here we will introduce you the Front view of the system of Dell PowerEdge R860, after reading this airticle, you are able to use this product more easyly. If you have any questions, please contact us immediately. Figure 1. Front view of 24 x 2.5-inch drive system Figure 2. Front view of 16 x 2.5-inch drive system Figure 3. Front view of 8 x 2.5-inch drive system Figure 4. Front view of 8 x EDSFF E3.S drive system Table 1. Features available on the front of the system Item Ports, panels, and slots Icon Description 1 Left control panel N/A Contains the system health, system ID, and the status LED indicator. 2 Drive N/A Enables you to install drives that are supported on your system. 3 Right control panel N/A Contains the power button, VGA port, USB port, iDRAC Direct (Micro-AB USB) port, and the iDRAC Direct status LED. 4 Express Service Tag N/A The Express Service Tag is a slide-out label panel that contains system information such as Service Tag, NIC, MAC address, and so on. If you have opted for the secure default access to iDRAC, the Information tag will also contain the iDRAC secure default password.
