PowerEdge R660 Processor Features and Supported processors
The PowerEdge Intel 4th Generation Xeon® Scalable Processors stack is the next generation data center processor offering with significant performance increases, integrated acceleration, and next generation memory and I/O . Sapphire Rapids accelerate customer usages with unique workload optimizations.
- 2023 - 06 - 09
Rear view of the system of Dell PowerEdge R550
Do you know the rear view of the system of Dell PowerEdge R550? Here we provide you with the rear view of the system overview of the Dell EMC PowerEdge R550. We will introduce you in detail in the form of pictures and tables. After reading this article，you will have a whole hearted understanding of the Dell EMC PowerEdge R550. Rear view of the system of Dell PowerEdge R550 ITEM PORTS, PANELS, OR SLOTS ICON DESCRIPTION 1 PCIe expansion card slot 1 N/A Enables you to connect PCI Express expansion cards. 2 PCIe expansion card slot 2 N/A Enables you to connect PCI Express expansion cards. 3 PCIe expansion card slot 5 N/A Enables you to connect PCI Express expansion cards. 4 System identification button Press the system ID button: To locate a particular system within a rack. To turn the system ID on or off. To reset iDRAC, press and hold the button for more than 16 seconds. 5 PCIe expansion card slot 6 N/A Enables you to connect PCI Express expansion cards. 6 BOSS S2 module N/A Enables you to connect BOSS S2 module. 7 Power supply unit (PSU 2) Indicates the PSU 2. 8 Power supply unit (PSU...
- 2023 - 06 - 07
Today’s topic: what is the features and transmission media of Mini SAS HD high-speed data cables.
Mini SAS HD high-speed transmission data cable transmission media are: SFF8643 data port 68PIN SFF8639 interface SATA 15PIN power connector Mini SAS HD high-speed transmission data cable functional features: Data port contact area gold-plated 15U" SFF8639 female end to SFF8643 + SATA 15PIN. data cable using LOTES brand terminal connectors. .Adopt nylon braid to enhance data cable flexibility and efficient transmission. 5.Cable length can be customized by OEM.
- 2023 - 05 - 26
Dell EMC PowerEdge R550 System overview
The new Dell EMC PowerEdge R550 is a 2U, dual-socket server that offers the best value for organizations seeking the latest processing, I/O, and storage capabilities.The PowerEdge R550 is a general-purpose platform capable of handling demanding workloads and applications, such as data warehouses, e-commerce, databases, and high-performance computing (HPC) .The target workloads for the PowerEdge R550 include light duty virtualization, small IT infrastructure and small business specific workloads . Figure 1. Front view of the 16 x 2.5-inch drive system ITEM PORTS, PANELS, AND SLOTS ICON DESCRIPTION 1 Left control panel N/A Contains the system health, system ID, status LED and the iDRAC Quick Sync 2 (wireless) indicator. Status LED: Enables you to identify any failed hardware components. There are up to five status LEDs and an overall system health LED (Chassis health and system ID) bar. For more information, see the Status LED indicators section. Quick Sync 2 (wireless): Indicates a Quick Sync enabled system. The Quick Sync feature is optional. This feature allows management of the system by using mobile devices called as OpenManage Mobile (OMM) feature. Using iDRAC Quick Sync 2 with OpenManage Mobile (OMM) aggregates hardware or firmware inventory and various system level diagnostic and error...
- 2023 - 05 - 17
Status LED indicators of Dell EMC PowerEdge R760
In order to enhance customers' understanding of Dell EMC PowerEdge R760, we have published a series of articles, in this article, we will introduce the Status LED indicators of Dell EMC PowerEdge R760 to you in the form of pictures and tables. Figure 1. Status LED indicators Table 1. Status LED indicators and descriptions ICON DESCRIPTION CONDITION CORRECTIVE ACTION Drive indicator The indicator turns solid amber if there is a drive error. Check the System Event Log to determine if the drive has an error. Run the appropriate Online Diagnostics test. Restart the system and run embedded diagnostics (ePSA). If the drives are configured in a RAID array, restart the system, and enter the host adapter configuration utility program. Temperature indicator The indicator turns solid amber if the system experiences a thermal error (for example, the ambient temperature is out of range or there is a fan failure). Ensure that none of the following conditions exist: A cooling fan has been removed or has failed. System cover, air shrouds, or back filler bracket has been removed. Ambient temperature is too high. External airflow is obstructed. Electrical indicator The indicator turns solid amber if the system experiences an electrical error (for example,...
- 2023 - 05 - 12
Cooling fan specifications of Dell EMC PowerEdge R760
In the previous article, we have made a detailed introduction to the performance of Dell EMC PowerEdge R760, in this article, we will introduce the cooling fan specifications of Dell EMC PowerEdge R760 to help you better understand the product. Cooling options The PowerEdgeR760 requires various cooling components that are based on processor TDP, storage modules, rear drives, GPU, and persistent memory to maintain optimum thermal performance. The PowerEdgeR760 offers two types of cooling options: Air cooling Direct Liquid Cooling (DLC) (optional) Cooling fan specifications The PowerEdgeR760system system supports up to six standard (STD), High performance Silver (HPR) grade , or High performance Gold (VHP) grade cooling fans. Table 1. Cooling fan specifications FAN TYPE ABBREVIATION LABEL COLOR LABEL IMAGE Standard (STD) fans STD No label High performance Silver (HPR) fans HPR Silver High performance Gold (VHP) fans VHP Gold
