Dell EMC Poweredge R740 Rack Server With 1U And 2U

    Dell EMC Poweredge R740 Rack Server With 1U And 2U

    Dell emc poweredge r740 is a type of dell rack server. Based on the latest dell cyber resilience architecture, security is embedded in each server to protect data in real time.


    Built-in Dell iDRAC9 capabilities for automated management.

    Equipped with ProSupport Plus and SupportAssist to reduce IT workload by at least 72%.

    3 double-width GPUs to scale VDI deployments.


    The PowerEdge R740 was designed to accelerate application performance leveraging accelerator cards and storage scalability. The 2-socket, 2U platform has the optimum balance of resources to power the most demanding environments.


    Expand and optimize application performance


    The scalable business architecture of the R740 can scale up to three 300W or six 150W GPUs, or up to three double-width or four single-width FPGAs. With up to 16 2.5" drives or 8 3.5" drives the R740 provides the versatility to adapt to virtually any application and provides the perfect platform for VDI deployments.

    • Scale your VDI deployments with 3 double-width GPUs, supporting up to 50% more users when compared to R730.

    • Free up storage space using internal M.2 SSDs optimized for boot.

    Scale compute resources with 2nd Generation Intel® Xeon® Scalable processors and tailor performance based on your unique workload requirements.


    Automate systems management with OpenManage


    The Dell EMC OpenManage™ portfolio helps deliver peak efficiency for PowerEdge servers, delivering intelligent, automated management of routine tasks. Combined with unique agent-free management capabilities, the R740 is simply managed, freeing up time for high profile projects.

    • Simplify management with the New OpenManage Enterprise™ console, with customized reporting and automatic discovery.

    • Take advantage of QuickSync 2 capabilities and gain access to your servers easily through your phone or tablet.


    Rely on PowerEdge with built-in security

    Every PowerEdge server is designed as part of a cyber resilient architecture, integrating security into the full server lifecycle. The R740 leverages new security features built-into every new PowerEdge server strengthening protection so you can reliably and securely deliver accurate data to your customers no matter where they are. By considering each aspect of system security, from design to retirement, Dell EMC ensures trust and delivers a worry-free, secure infrastructure without compromise.

    • Rely on a secure component supply chain to ensure protection from factory to the data center.

    • Maintain data safety with cryptographically signed firmware packages and Secure Boot.

    • Protect your server from malicious malware with iDRAC9 Server Lockdown mode (requires Enterprise or Datacenter license)

    • Wipe all data from storage media including hard drives, SSDs and system memory quickly and securely with System Erase.




    Technical Specification


    Up to two 2nd  Generation Intel® Xeon®  Scalable processors, up to

    28 cores per processor


    24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to

    2933MT/s, 3TB max, Up to 12 NVDIMM, 192 GB Max

    Up to 12 Intel®  Optane™ DC persistent memory PMem, 6. 14TB max

    Supports registered ECC DDR4 DIMMs only

    Storage controllers


    Internal Boot

    Internal Controllers: PERC H330, H730P, H740P, HBA330, H750, HBA350i

    External Controllers: H840, HBA355e, 12 Gbps SAS HBA

    Software RAID:S140

    Boot Optimized Storage Subsystem (BOSS):HWRAID 2 x M.2 SSDs 240GB, 480GB

    Internal Dual SD Module1


    Front drive bays: Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 122.88TB or

    up to 8 x 3.5” SAS/SATA HDD max 128TB Optional DVD-ROM, DVD+RW

    Power supplies

    Titanium 750W, Platinum 495W, 750W,

    750W 240VDC,2  1100W,

    1100W 380VDC2

    1600W, 2000W and 2400W, Gold 1100W -48VDC

    Hot plug power supplies with full redundancy

    Up to 6 hot plugs fans with full redundancy


    Form factor: Rack (2U)

    Height: 86.8mm (3.4”)

    Width3 : 434.0mm (17.08”)

    Depth3 : 737.5mm (29.03”)

    Weight: 28.6kg (63lbs.)

    Embedded management

    iDRAC9, iDRAC Direct, iDRAC RESTful with Redfish, Quick Sync 2

    wireless module (optional)


    Optional LCD Bezel or Security bezel

    OpenManage™ Software

    OpenManage Enterprise

    OpenManage Mobile

    OpenManage Power Manager

    Integrations and



    Microsoft®  System Center

    VMware®  vCenter™

    BMC Truesight

    Red Hat® Ansible®  Modules


    Nagios®  Core & Nagios® XI

    Micro Focus Operations Manager I

    IBM Tivoli Netcool/OMNIbus


    TPM 1.2/2.0, TCM 2.0 optional

    Cryptographically signed firmware

    Secure Boot

    System Lockdown (requires iDRAC Enterprise

     or Datacenter)

    Secure erase Silicon Root of Trust

    I/O & Ports

    Network daughter card options

    4 x 1GbE or 2 x 10GbE + 2 x 1GbE or 4 x 10GbE or 2 x 25GbE

    Front ports: 1 x Dedicated iDRAC Direct Micro-USB, 2 x USB 2.0,

    1 x USB 3.0 (optional), 1 x VGA

    Rear ports: 1 x Dedicated iDRAC network port, 1 x Serial,

    2 x USB 3.0, 1 x VGA

    Video card: 2 x VGA

    Riser options with up to 8 PCIe Gen 3 slots, maximum of 4 x 16 slots

    Accelerator options

    Up to three 300W or six 150W GPUs, or up to three double-width or four

    single-width FPGAs.

    Supported systems operating

    Canonical® Ubuntu®  Server LTS

    Citrix®  Hypervisor

    Microsoft Windows Server®  LTSC with Hyper-V

    Oracle®  Linux

    Red Hat®  Enterprise Linux

    SUSE®  Linux Enterprise Server

    VMware®  ESXi

    For specifications and interoperability details,

    OEM-ready version


    From bezel to BIOS to packaging, your servers can look and feel as if they were

    designed and built by you.
