    Air ANT2566P4W R Cisco 2566 Antenna

    Air ANT2566P4W R Cisco 2566 Antenna

    Air ANT2566P4W R is a model of a Cisco antenna that is equipped with a 2.4-5 GHz and 6 dbi directional antenna that can penetrate concrete walls.

    Features

    Based on the 802.11n standard protocol, it supports multiple inputs and outputs.

    The signal can penetrate concrete walls and emphasis will not be weakened.

    6 dBi directional antenna with 4 ports, can connect multiple digital devices.

    YouTube

    Parameters

    Brand

    Cisco

    Product Model

    Air ANT2566P4W R

    Product Type

    Antenna

    Antenna type

    4-element dual-band MIMO

    Operating frequency range

    2400 to 2484 MHz   5150–5850 MHz

    Gain

    6 dBi in both bands

    Polarization

    Linear, vertical

    Length

    6.3 in. (16 cm)

    Width

    11 in. (27.9 cm)

    Depth

    1.2 in. (3.05 cm)

    Cable length and type

    3 ft. (91.4 cm) plenum rated

    Connector

    RP-TNC

    Environment

    Indoor/outdoor

    Water/Foreign Body Ingress

    IP54

    Warranty

    1 year
