    Huawei POE Switch S3700 28TP PWR SI

    Huawei POE Switch S3700 28TP PWR SI

    S3700 28TP PWR SI is a Layer 3 switch in Huawei 3700 series switches. Built-in 2 Gigabit Ethernet ports and hot-swappable power supplies provide an effective solution for network management.

    Features



    The Smart Ethernet Protection (SEP) function protects the security of the network in real time.

    24 Ethernet 10/100 PoE ports can connect multiple external devices simultaneously.

    Hot-swap capability ensures the longevity of the switch.

    YouTube



    Parameters



    Ports description

    24*10/100Base-TX

    2*1000Base-X, 2*GE Combo

    MAC address table

    IEEE 802.1d compliance
    16K MAC address entries
    MAC address learning and aging
    Static, dynamic, and blackhole MAC address entries
    Packet filtering based on source MAC addresses

    VLAN

    4K VLANs
    Guest VLANs, voice VLAN, and super VLAN
    MUX VLAN and GVRP
    VLAN assignment based on MAC addresses, protocols, and IP subnets
    QinQ
    Selective QinQ
    1:1 VLAN mapping
    N:1 VLAN mapping

    Reliability

    RRPP (ring topology, intersecting rings, and multi-instance), implementing protection switchover within 50 ms
    Smart Link tree topology and Smart Link multi-instance, providing the millisecond-level protection switchover
    STP(IEEE 802.1d), RSTP(IEEE 802.1w), and MSTP(IEEE 802.1s)
    BPDU protection, root protection, and loop protection
    Smart Ethernet Protection (SEP)

    IP routing

    Static routing, RIPv1, RIPv2, and ECMP

    IPv6 features

    Neighbor Discovery (ND)
    Path MTU (PMTU)
    IPv6 ping, IPv6 tracert, and IPv6 Telnet
    Manually configured tunnel
    6to4 tunnel
    ISATAP tunnel
    ACLs based on the source IPv6 address, destination IPv6 address, Layer 4 ports, or protocol type
    MLD v1/v2 snooping

    Multicast

    1 K multicast groups
    IGMP v1/v2/v3 snooping and IGMP fast leave
    Multicast VLAN and multicast replication between VLANs
    Multicast load balancing among member ports of a trunk
    Controllable multicast
    Port-based multicast traffic statistics

    QoS/ACL

    Rate limiting on packets sent and received by an interface
    Packet redirection
    Port-based traffic policing and two-rate three-color CAR
    Eight queues on each port
    WRR, DRR, SP, WRR+SP, and DRR+SP queue scheduling algorithms
    Re-marking of the 802.1p priority and DSCP priority
    Packet filtering on Layers 2 through 4, filtering out invalid frames based on the source MAC address address
    Rate limiting in each queue and traffic shaping on ports

    Security

    User privilege management and password protection
    DoS attack defense, ARP attack defense, and ICMP attack defense
    Binding of the IP address, MAC address, interface, and VLAN
    Port isolation, port security, and sticky MAC
    Blackhole MAC address entries
    Limit on the number of learned MAC addresses
    802.1x authentication and limit on the number of users on an interface
    AAA authentication, RADIUS authentication, HWTACACS authentication, and NAC
    SSH v2.0
    CPU defense
    Blacklist and whitelist

    Surge protection

    6KV surge protection capability on service ports (1KV on service ports on PoE devices)

    Management and maintenance

    iStack
    MAC Forced Forwarding (MFF)
    Remote configuration and maintenance using Telnet
    Auto-Config
    Virtual cable test
    Ethernet OAM (IEEE 802.3ah and 802.1ag)
    Dying gasp power-off alarm (S3700-28TP-EI-MC-AC)
    SNMP v1/v2c/v3 and RMON
    Web NMS

    Operating environment

    Operating temperature: 0℃–50℃(long term);
    Relative humidity: 10%–90% (non-condensing)

    Power supply

    AC:
    Rated voltage range: 100V to 240V AC; 50/60 Hz
    Maximum voltage range: 90V to 264V AC; 50/60 Hz
    DC:
    Rated voltage range: –48V to –60V DC
    Maximum voltage range: –36V to –72V DC
    Note: PoE-support switches do not use DC power supplies.

    Dimensions (W x D x H)

    442 mm x 420 mm x 43.6 mm

    Weight

    S3700-28TP-PWR-SI<4Kg
    (without power supply)

    Power consumption

    S3700-28TP-PWR-SI<818W
    (PoE: 740W)
